For UAN system
- length - 7 490 mm
- width - 2 250 mm
- height - 2 890 mm
- unladen weight - 3 800 kg
- gross weight - 13 800 kg
- tank capacity - 10 000 l
- number of wheels - 4
- wheel track - 2 000 mm
- tyres - 20,5 R22,5
- vertical load - 16 KN
- tractor horsepower - 100 KM
- filling time - 5 min
- spreading spoon spilling width - 14 m
- compressor type - JUROP PN 58M
- compressor capacity - 6 500 l / min
A slurry tanker has got the following components in its standard equipment:
- 4" suction hose 6 m long, with a suction strainer and fire coupling
- 2" hose with a valve and discharge knee
- 2" discharge pipe with a valve
- compressor with a safety valve
- damper - oil recuperator
- float valve in the upper part of the tank
- overflow tank
- sight-glasses in the front head
- manometer
- adjustable supporting foot
- replaceable tow eye
- single-line braking system
- 12 V electrical system
- hydraulic system for opening the discharge valve
- mudguards
A slurry tanker, beside its standard version, can also be manufactured in a special version and can have
additional components, extending its functionality:
- closed rear head with Ø600 mm hatch
- hydraulic or manual brass gate valves on one side or at the back of the tank
- Ø 420 mm upper hatch, manual or hydraulic
- ladder
- glass-tube level indicator
- fittings to transport the slurry
- compressor PN 84M
- PTO shaft
- sprinkling distributors for backward or sideward
- double-line braking system
- swivel tow eye or other
- rear steering axle
