PN - 100/2 economical
- length - 7 490 mm
- width - 2 550 mm
- height - 2 890 mm
- unladen weight - 3 100 kg
- gross weight - 11 600 kg
- tank capacity - 10 000 l
- number of wheels - 2
- wheel track - 2 000 mm
- tyres - 20.5 R22.5
- vertical load - 16 KN
- tractor horsepower - 100 HP
- filling time - 5 min
- spreading spoon spilling width - 14 m
- compressor type - JUROP PN 58M
- compressor capacity - 6 500 l / min
| Capacity | PN-100/2 verson |
Number of axles | Wheel track | Wheel setback | Tyres | Compressor |
| 10 000 litres | version A standard |
1 | 2000 | 280 / 335 / 10 |
20,5 R22,5 retread |
JUROP PN 58M |
| version B | 1 | 2150 | 280 / 335 / 10 |
700 / 50 - 22,5 |
JUROP |
|
| version C | 1 | 2100 | 280 / 335 / 10 |
600 / 55 - 23 retread |
JUROP |
|
| version D | 1 | 2000 | 280 / 335 / 10 |
560 / 60 x 22,5 |
JUROP |
A slurry tanker has got the following components in its standard equipment:
- 4" suction hose 6 m long, with a suction strainer
- compressor with a safety valve
- lifted spreading spoon
- damper - oil recuperator
- mudguards
- float valve in the upper part of the tank
- overflow tank
- Ø 600 mm rear hatch
- sight-glasses in the front head
- manometer
- adjustable supporting foot
- replaceable tow eye
- single-line braking system
- 12 V electrical system
- hydraulic system for opening the discharge valve
A slurry tanker, beside its standard version, can also be manufactured in a special version and can have additional components, extending its functionality:
- tyres 700/50x22.5; 600/65x23;or 560/60x22.5
- opened rear head
- tank with special paint coating
- hydraulic or manual brass gate valves on one side or at the back of the tank
- Ø 420 mm upper hatch, manual or hydraulic
- ladder
- glass-tube level indicator
- discharge pipe with a 2" valve
- compressor PN 84M or other
- PTO shaft
- sprinkling distributors for backward or sideward
- double-line braking system
- swivel tow eye or other
