PN - 60/3 economical

  • length - 6 050 mm
  • width - 2 315 mm
  • height - 2 510 mm
  • unladen weight - 1 850 kg
  • gross weight - 7 850 kg
  • tank capacity - 6 000 l
  • number of wheels - 2
  • wheel track - 1 800 mm
  • tyres - 400 R22,5
  • vertical load - 10 KN
  • tractor horsepower - 60 HP
  • filling time - 4 min
  • spreading spoon spilling width - 14 m
  • compressor type - JUROP PN 45M
  • compressor capacity - 5 300 l / min
Capacity PN - 60 / 3
version		 Number of axles Wheel track Wheel setback Tyres Compressor
6 000 litres version A
standard		 1 1900 220 / 275 / 8 400 R22,5
retread 		 JUROP
PN 45M
version B 1 2000 220 / 275 / 8 550 / 60 - 22,5

JUROP
PN 45M
version C 1  2000 220 / 275 / 8 600 / 65 x 23
retread

JUROP
PN 45M
version D 1  2000 220 / 275 / 8 20,5 R22,5
retread

JUROP
PN 45M
version E  1  2000 220 / 275 / 8 560 / 60 x 22,5

JUROP
PN 45M
version F  1  2150 220 / 275 / 8 700 / 50 - 22,5

JUROP
PN 45M

A slurry tanker has got the following components in its standard equipment:

  • 4" suction hose 6 m long, with a suction strainer
  • compressor with a safety valve
  • lifted spreading spoon
  • damper - oil recuperator
  • mudguards
  • float valve in the upper part of the tank
  • overflow tank
  • Ø 600 mm rear hatch
  • sight-glasses in the front head
  • manometer
  • adjustable supporting foot
  • replaceable tow eye
  • single-line braking system
  • 12 V electrical system
  • hydraulic system for opening the discharge valve

A slurry tanker, beside its standard version, can also be manufactured in a special version and can have additional components, extending its functionality:

  • tyres 550/60x22.5; 600/65x23; 20,5 R22.5; 560/60x22.5 or 700/50x22.5
  • opened rear head
  • tank with special paint coating
  • hydraulic or manual brass gate valves on one side or at the back of the tank
  • Ø 420 mm upper hatch, manual or hydraulic
  • ladder
  • glass-tube level indicator
  • discharge pipe with a 2" valve
  • compressor PN 58M or other
  • PTO shaft
  • sprinkling distributors for backward or sideward
  • double-line braking system
  • swivel tow eye or other
